XP Power FS02-12

XP Power Isolated DC to High Voltage DC Converters FS Series

FS Series converters provide a rigid design with enhanced features for long term reliability.

Features and Benefits

• Output proportional and linear to output <0.7V turn on voltage
• Smart features for enhanced reliability
• Over temperature protection with automatic shutdown and error code
• Over voltage protection with automatic shutdown error code output
• Disable pin
• No minimum load current needed
• Quasi-Sinewave Oscillator
• Low conducted emissions
• Low input ripple current
• Operating range with stable operating frequency
• High input to output galvanic isolation
• Leakage current and coupling capacitance low input/output
• Reversible output polarity
• High efficiency
• Robust
• Arc protection
• Short circuit protection
• Internal thermal management
• Anodized aluminium heatsink surface
• Two threaded blind inserts allowing easy heatsinking and/ or chassis mounting options

Applications

• Electrophoresis
• Piezo devices
• Capacitor charging
• Mass spectrometry
• Electrostatic chucks

Isolated DC to High Voltage DC Converters

Standards

UL, 94-0 Flammability, RoHS
