Safety Controller CPU, Standalone

OMRON Safety Controller, Insulated, DIN Rail Mounting - NX Series - NX-SL3300

Keep a close watch over your industrial sensors with this safety controller from OMRON. It reduces the risk of injury in potentially dangerous locations such as material handling and manufacturing plants by monitoring its inputs for failures or malfunctions. Thanks to its expandable system, you can connect up to 32 safety devices while monitoring as many as 63 standard components. For your protection, the unit is insulated to minimise the chance of electric shocks. Compact dimensions of 100 (L) x 30 (W) x 71mm (D) help you get the most out of your panel packing space. This versatile controller is suitable for communicating between various devices, such as e-stop buttons, relays, inverters and light curtains.

Features & Benefits

• Includes hooks for quick and easy DIN rail installation
• Pull-out tabs for fuss-free unit removal
• Low maximum power consumption of 0.9W makes it energy-efficient
• Light weight of 75g puts minimal strain on a DIN rail

Applications

• Automotive manufacturing
• Medical facilities
• Oil and gas industries
• Logistics hubs

Does this safety controller have areas for labelling?

Yes, the component is conveniently supplied with pre-attached markers. This lets you quickly identify your connected devices.

Omron NX Standalone Safety Controller

The NX series safety control units offer simple and flexible design for high-speed, high-precision motion control and safety control in an integrated engineering environment when used in conjunction with the NJ series machine automation controller and the automation software Sysmac Studio. This functionality contributes to productivity improvements and assurance of safety conforming to international standards and rules.

• Integrated safety into machine automation possible by connecting with the NX-series EtherCAT Coupler
• The Safety CPU Unit controls up to 128 Safety I/O Units
• 4 or 8 points per Safety Input Unit, the 4-point Safety Input Unit can be directly connected with OMRON Non-contact Switches and Single beam Sensors
• 2 or 4 points per Safety Output Unit, the 2-point Safety Output Unit is characterized by large output breaking current of 2.0 A
• The Safety Units can be freely allocated in any combination with standard NX I/O
• Compliant with IEC61131-3
• Safety programs can be standardized and reused efficiently by using POUs for design and operation
• EN ISO13849-1 (PLe/Safety Category4), IEC 61508 (SIL3) certified
• One connection using Safety over EtherCAT (FSoE) protocol enables flexible configuration by mixing the Safety Units with standard NX I/O
• Hardware and safety circuits can be configured using the Sysmac Studio (Ver. 1.07)
