Limit switch spoke actuator

Honeywell HDLS Series Limit Switch, Lever Accessory, Standards/Approvals Compliant - LSZ69CA

This limit switch is an accessory designed to operate with HDLS series devices, providing a mechanical actuation option for control systems in industrial settings. It functions as a lever-type add-on that converts physical movement into a switching action and is intended for use where electrostatic discharge considerations and regulatory adherence are relevant.

Features and Benefits:

• Lever-mounted actuation increases mechanical input versatility
  Compatibility with HDLS range simplifies replacement integration
  Conforms to ANSI/ESD S20.20
• supports ESD-sensitive environments
  Meets RoHS requirements
• reduces hazardous substance risk
  Complies with BS EN 61340-5-1
• aids controlled electrostatic protection

Applications

• Suitable for factory automation limit detection tasks
  Ideal for use in electronics assembly lines requiring ESD control
  Used with HDLS devices for machinery position sensing
  Can be used for electrical panel interlock signalling

How does it Interface mechanically with existing devices?

It connects as a lever accessory to the HDLS family, providing a pivoting contact point that transmits mechanical motion to the switch mechanism.

Is it appropriate for environments where electrostatic discharge is a concern?

Yes, it is designed in accordance with ANSI/ESD S20.20 and BS EN 61340-5-1 considerations to minimise ESD risk during handling and operation.

What regulatory environmental constraint does it address?

The component is compliant with RoHS, limiting the use of specific hazardous substances in its construction.

Which users will find this accessory most relevant?

Engineers and technicians in automation, electrical, mechanical and electronics fields who need a replacement lever or a supplementary actuation option for HDLS devices will find it applicable.

Standards

EN60947-5-1, IEC947-5-1

Approvals

UL, CSA
