Pulse Isolator 5202B2
Техническая документация
Характеристики
Brand
PR ElectronicsКоличество каналов
2
Тип продукции
Galvanic Barrier
Barrier Type
Galvanic Barrier
Тип монтажа
DIN-рейка
Сертификация опасной зоны
ATEX
Тип клеммы
Винт
Степень защиты
IP20
Напряжение питания
21.6 to 253 V ac, 19.2 to 300 V dc
Maximum Safety Current
400mA
Минимальная рабочая температура
-20°C
Maximum Safety Voltage
250V ac
Максимальная рабочая температура
60°C
Стандарты/одобрения
NE 21, SIL 2/3 Full Assessment IEC 61508, IECEX, ATEX, SIL 2, Hardware Assessment, EAC, FM, Zone 2-DIV 2, SIL 2 Full Assessment IEC 61508, DNV-GL / EU-RO marine, UL 61010 / 508, NE 43, Zone 2
Серия
5200
Страна происхождения
Denmark
Информация о товаре
PR Electronics 5202B Ex Pulse Isolator
PR Electronics 5202B pulse isolator for transmission of signals to the safe area from NAMUR sensors installed in hazardous areas. This signal conditioning isolator measures one or more pulse inputs and provides an identical number of isolated pulse outputs. The PR 5202B uses transformer and optical isolation techniques to provide 3.75 kVac galvanic isolation between the input, output and power terminals. The high level of electrical isolation means that input pulses sensed at the 5202B are not electrically connected to the output pulse. The 5202B has been designed, developed and certified for use in SIL 2 applications according to the requirements of IEC 61508.
Besides providing isolation, the PR 5202B is a barrier. This means that the module can make an intrinsically safe measurement of contacts and NAMUR sensors mounted in a zone 0/ Division 1 explosion hazard area. The PR 5202B limits the level of energy present at the contact or the NAMUR sensor to a low intrinsically safe level, thereby preventing ignition of a flammable atmosphere around the sensor – even if the sensor or the cable is damaged.
PR Electronics - Ex Interfaces
